Common Applications
Application Views 3Com PortSwitch Hubs
5-2 Management Module Guide
Common Applications
This device supports the following common applications described in the MIB
II Applications Reference:
• MIB-II (SNMP2_Agent)
- ICMP (ICMP_App)
- IP (IP2_App)
- System (System2_App)
- TCP (TCP2_App)
- UDP (UDP2_App)
The Standard RMON application is available if you purchase the associated
service. This application is described in its management module guide.
Device Application View
This view shows the common and device-specific applications supported by
this device and provides access to application-specific information.
See Chapter 1, Introduction , for information on Accessing SPECTRUM Views .
Figure 5-1 provides an example of an Application view in the icon mode.
Figure 5-2 provides an example of an Application view in the list mode.
To change the display mode, select View -> Mode -> List or Icon.
