CONTENTS
PREFACE ....................................
MAIN FEATURES ........................
PRECAUTIONS ...........................
MAJOR OPERATING CONTROLS
A.
A-1. Power -
A-2. Reset •
Factory Preset Operation mode
B.
B-1.
B-2.
B-3.
B-4.
B-5.
Audio Mixer
C.
D.
D-1. Mix .
D-2. Wipe
1. W
1 2. Wipe Edge ...................................... ........... 18
1 3. Wipe Direction ................................. ........... 19
2 D-3. Luminance Key ..................................... ........... 19
D-4. Pattern Table ......................................... ........... 20
3 D-5. Picture-in-Picture .................................. ........... 22
12 E. Basic Operation 4 ......................................... ........... 22
13 E-1. Downstream Key ................................... ........... 22
13 E-2. External Key .......................................... ........... 23
13 F. Basic Operation 5 .......................................... ........... 24
13 F-1. Video Fade-Out (In) ............................... ........... 24
14 F-2. Down stream Key Fade-Out (In) ........... ........... 24
14 F-3. Audio Key Fade-Out (In) ....................... ........... 25
14 G. Basic Operation 6 ......................................... ........... 25
15 H. Applications ................................................... ........... 26
15 Fl-1. Event Memory Functions ...................... ........... 26
16 FI-2. Auto Take ............................................. ........... 26
16 FI-3. Digital Effects ....................................... ........... 26
18 INTERFACE ...................................................... ........... 28
18 SPECIFICATIONS ............................................. ........... 29
18 OPTIONAL ACCESSORIES .............................. ........... 29
18
PREFACE
The Panasonic Digital AV Mixer WJ-MX30 is designed for
use in producing special-effect images by utilizing the
built-in Frame Synchronizer and other digital processing
circuits. In addition to the Mix Effect of .the conventional
Digital AV Mixer, the WJ-MX30 offers such features as
Luminance Key function, Digital Effect, Downstream Key
Effect, Wipe Effect, Fade Control, Memory and many more.
This operating manual is intended to explain the Generator’s
many operational features. With the WJ-MX30 and your
imagination there are many possible function combinations
which are left to your creativity.
MAIN FEATURES
Built-in Frame Synchronizers for A-bus and B-bus.
Three audio/video source inputs.
Digital Effects such as Nega, Mosaic, Mono, Paint, Still,
Strobe, Scramble and AV Synchro.
Several combinations of the Luminance Key, Mix,
and/or Wipe.
107 Wipe-pattern combinations are available.
9 standard background matte-colors are available from
the Matte Generator.
Audio fade, DSK fade and/or video fade are available
either independently or in combination.
The interval time for Auto-Fade and Auto-Take can be
adjusted independently.
9. The audio level can also be linked with the movement
of the Wipe lever.
10. Up to 8 events can be stored in the memory.
11. Advance Sync signal output connectors for use with
VTR editing systems.
12. External key function is provide.
13. Reset function for returning to the preset condition at
the factory.
14. The modes selected by buttons will be kept by memory
back up approximately 1 week even if AC power is
disconnected.
1 -
