Index of Controls

Multi Function Display

VCR Indicator
Appears when the VCR/TV
selector is set to VCR.

Power Indicator
This indicator lights
when power is turned on.

Hi-Fi Indicator
When Hi-Fi audio is monitored or
played back, this indicator appears.

Timer Indicator
This indicator lights when the VCR

is set for a Timer Recording, or if a
length is set for normal recording.
It flashes when a Timer Recording
has been set, but a tape has not
been inserted into the VCR.

Clock/Status/Channel Dispiay
Displays the current time.
Briefly displays VCR status when function button is pressed.
Also, briefly displays the channel number selected, “L” when
channel button is pressed or select a line input.

Rear View of the VCR
