Specifications
GENERAL I
Power Supply 12 V DC (11 V -16 V): test Voltage, 14.4 V; negative ground
Current Consumption 8.5 A (at rated tape operation outputr)
Rated output 13 W X 4 channels (1 OOHz, 1 %, 4Q)
Maximum output 30 W X 4 channels
Suitable speaker impedance 4Q
Audio ¡input impedance lOka
Audio iinput sensitivity 600mmV
PRE-OUT output voitagey SOOmmV
PRE-OUT output impedance 600Q
External dimensions 178 (W)x100 (H)x160 (D) mm
Weight 3.2kg
Tuners
FM Tuners
Frequency range 87.5 to 108.0 MHz
Useable sensitivity 12dBf
Total harmonic distortion (mono) 0.3% (1kHz)
Weighted S/N ratio (mono) 70dB
Frequency response 20 to 15,000 Hz ±3 dB
Stereo separation 42dB (1kHz)
Image-rejection ratio 65 dB
AM Tuners
Frequency Range 531 to 1,602 kHz
Useable Sensitivity (S/N 20dB) 27 dB/pV
Image-jamming ratio 65 dB
Cassette Tape Player
Reproduction system 4-track, 2-program stereo
Tape speed 1-7/87sec (4.76 cm/sec)
Fast forward time lOOsec(C-eO)
Rewind time 100 sec (C-60)
Wow and flutter 0.07% (WRMS)
Signai/Noise ratio Dolby NR OFF 56 dB (IHF, A)
Dolby NR ON 66 dB (IHF, A)
Frequency response 30 to 18,000 Hz (normal tape)
30 to 20,000 Hz (metal tape)
CD Player
Number of channel 2 channels
Quantization 16-bit linear (4.76 cm/sec)
Frequency response 5 to 20,000 Hz (±1 dB)
Dynamic range 90dB(1kHz)
Wow and flutter Below measurable limits
DSP
Number of channel 2 channels for Input; 4 channels for output
Reverberation level adjustment 7 steps
Equalizer center frequency 80,160, 320, 640,1.6k, 4k, 10k (Hz)
Equalizer range -12 dB to +12 dB (13 step)
Note:
Specifications and design are subject to modification without notice due to improvements in technology.
Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
“DOLBY" and the double-D symbol □□ are trademarks of Dolby Laboratories Licensing Corporation.
52
CQ-VX777EW
