Setting GEQ
0 Press SELECT to select GEQ mode.
@ • Press (frequency selection buttons) to select a
frequency.
Any of the seven frequency bands (80 Hz, 160 Hz, 320 Hz, 640
Hz, 1.6 kHz, 4 kHz, 10 kHz) can be selected. The flashing
cursor moves to the left or right each time the corresponding
button is pressed.
The fiashing cursor move leftward (bass) when is pressed.
The flashing cursor move rightward (treble) when is
pressed.
Move the flashing cursor to the frequency position you wish to
adjust.
• Press«, '•►to adjust the level.
0 dB when the cursor is at the center. Any of the 13 levels can
be selected from +12 dB (cursor at the highest position) to -12
dB (cursor at the lowest position).
Press ■ to raise the level.
Press ■•►to lower the level.
Note;
Make the above adjustment while the mode is displayed (for about 5 seconds). If no button is pressed
while it is displayed, it automatically returns to normal mode. In such a case, press SELECT again to
select GEQ.
GEQ in the Memory
© Press SELECT to select GEQ mode.
© Press the preset button (1 to 6) you wish to save in the memory.
© Set the desired GEQ.
Note:
if a preset button once saved in the memory is preset again, the
GEQ saved in the memory is erased.
CQ-VX777EW
11
