OPERATION: GENERAL
(Continued)
The HEQ matrix display is as shown below.
button
button
Softs HeavyS Soft2 Heavy3 Softt HeavyS —Heavy3 Sharpi HeavyS Sharp2Heavy3 SharpSHeavyS
Softs Heavy2 Soft2 Heavy2 Softi Heavy2 —Heavy2 Sharp IHeavyS Sharp2Heavy2 SharpSHeavyS
Softs Heavyi Soft2 Heavyf Softl Heavyi —Heavyi Sharpi Heavyi Sharp2Heavy1 SharpSHeavyI
Softs -™ Soft2 — Softi — ■FLAT Sharpi— Sharps— Sharps—
Softs Lighti Soft2 Lighti Softl Lighti —Lighti Sharpi Lighti SharpSLightI SharpSUghtl
Softs Light2 Soft2 Light2 Softi Lights —Lights Sharpi Lights SharpSLightS SharpSLightS
Softs Lights Soft2 Lights Softl Lights —Lights Sharpi Lights ShaipSLightS SharpSLightS
button
button
Human Equalizer Position Image
Center; HEQ flat
: Heavy, adjustable in three
steps 1 to 3.
: Light, adjustable in three steps
1 to 3.
: Sharp, adjustable in three
steps 1 to 3.
: Soft, adjustable in three steps 1
to 3.
The vertical axis for the adjustment of
the heavy and light components of
sound (mainly bass)
The horizontal axis for the adjustment
of the sharp and soft components of
sound (mainly treble)
Select any of the 49 kinds of sound by
operating the buttons to suit your liking.
The display shows the position of the
selected sound at left and the equalizer
curve for the selected sound at right.
Soft treble Sharp treble
