Panasonic DVD-RV41 - Manual (Page 24)

&
0
c
1
A , T , ^ ,
ENTER
@ Numbered
buttons
Front (L) ; i Center
©Exit
L
©Test
signal
SETUP
SELECT
rt>J •4r
hét ÌI rn
Front (R)
□
I ■ . _ f - •■'L ■ =
SA ^
Exir I
Test I
dB
HI
d B ms d B
K i H a n i
dB
Surround Subwoofer;
HP.. . -P. - .. 0 -0-.
fS
@ No © Large © Small
RQT5869
® FRONT (L) ^CENTER
T
SURROUND (L)<----------
-^FRONT(R)
;
SURROUND(R)
Changing Initial settings
Speaker setting
Select either “2-channe!’’ or “Multi-channel” to suit the speakers you
have connected. You can change the following settings when you
select “Multi-channel”.
Speaker presence and size |
1. Press ►] to select the item and press [ENTER],
2. Press [ A , T ] to select the setting and press [ENTER],
Icon examples: Surround speaker (L)
Large: when the speaker supports low-frequency (under 100 Hz)
reproduction.
Small: Select when the speaker does not support low-frequency
reproduction.
The size setting for the front speakers is automatically determined by
the setting for the subwoofer.
Delay time
(Dolby Digital, center and surround speakers only)
For optimum listening with 5.1-channel sound, all the speakers, ex­
cept for the subwoofer, should be the same distance from the seating
position. If you have to place the center or surround speakers closer
to the seating position, adjust the delay time to make up for the differ­
ence.
if distance © (from the center speaker) and © (from the surround
speakers) are the same as or greater than ® (from the front speak­
ers), leave the delay time as “0”, the factory preset.
If either distance (g) or © is less than ®, find the difference in the
relevant table and change to the recommended setting.
•Center speaker
Difference Setting
Approx. 50 cm 1.3 ms
Approx. 100 cm 2.6 ms
Approx. 150 cm 3.9 ms
Approx. 200 cm 5.3 ms
•Surround speakers
Difference Setting
Approx. 200 cm 5.3 ms
Approx. 400 cm 10.6 ms
Approx. 600 cm 15.9 ms
Changing the delay time
1. Press [!,▼,◄, ►] to select the delay time box and press
[ENTER],
2. Press [A, ▼] to adjust the delay time and press [ENTER],
Channel balance
1
,
3.
Press [A, ▼, ◄, ►] to select “Test” and press [ENTER],
A test signal is output from one speaker at a time, starting with the
front left speaker and proceeding clockwise. (©)
While listening to the test signal, press [A, ▼] to adjust the
volume of the center and surround speakers so they are the
same apparent volume as the front speakers.
(The front speakers cannot be adjusted here.)
Press [ENTER].
(The test signals are stopped.)
No signal is output for the subwoofer. To adjust its volume, play
something, then return to this screen to adjust to suit your taste.
When you are finished
Press [A, ▼, ◄, ►] to select “Exit” and press [ENTER],
