Panasonic PV-4611 - Manual (Page 21)

VCR Plus+ programming allows you to set most items of a timer recording by simply entering a special code found in TV GUIDE
magazine as well as the TV listings in selected newspapers. In order for the VCR to read this special code, some set up is required.
A Guide (VCR Plus+) channel number is assigned to each local broadcast and cable station. Because this number sometimes
differs from the channel your TV receives the station on, it is necessary to program the VCR with local channel information.
o o o
O @ ® ©
Q У У Q
0S0 o
CLEAR'
Channel Set Up Preparations
NOTE; Complete the steps on this page if your
VCR hook-up resembles "B” on page 20.
Prepare a list like the example below.
This list will help you smoothly enter the information
needed in step 4 at right.
You will need the following to complete the list:
■ A line up of normal and/or cable stations you
receive along with the channel numbers your TV
receives them on. A cable channel line-up chart
is supplied by your cable company.
H A list of Guide (VCR Plus+) channel numbers
assigned to the stations you receive. This list is
available in TV Guide and the TV listings found
in selected newspapers.
•i Make a chart with 3 columns like the example
below. In the left column, fill in the name or call
letters of the stations you receive.
2 In the middle column, fill in each station’s
assigned Guide (VCR Plus+) number found in
TV Guide, newspapers, etc.
Q In the right column, fill in the channel number
^ that your TV receives the station on from your
channel line-up.
EXAMPLE ONLY
Broadcast or Cable
Station Name
Assigned
Guide
(VCR Pius+)
channei no.
Channei no.
yourTV
receives the
station on
HBO 33 15
Nickelodeon 38 20
CBS 04 04
FOX 11
VCR Plus+ Channel Set Up
(For connection B on page 20 only)
MENU
Push MENU
to display the
menu.
Rotate and push
the WHEEL to
select SET UP
CHANNEL
.............................. MENU ......................................
SET UP VCR
SET CLOCK
SET UP CHANNEL
IDIOMA/LANGUE:ENGLISH
SELECT
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
Rotate and push
the WHEEL to
select VCR Plus-i-
CH SETUP.
--- SET UP CHANNEL ---
AMTENNA SYSTEM : CATV
AUTO SET
«fliKJiygya.ijf
SELECT
SET
END
ROTATE WHEEL
PUSH WHEEL
PUSH MENU KEY
IMPORTANT NOTE:
For this step, use the list you prepared. You may leave lines
blank if, you don't receive that station, or the GUIDE CH
number and the CATV (or TV) CH numbers are the same.
Push the WHEEL
to move the
shaded area on
the right side.
VCR CH SET UP
GUIDE CH CATV CH
-• on
_
02 --
SELECT : ROTATE WHEEL
SET PUSH WHEEL
END PUSH MENU KEY
L________________________________________
Then, rotate the Wheel
to change CATV CH number.
Next, push the Wheel
to enter CATV CH number.
Now, rotate the Wheel to continue.
Repeat this operation until the list is complete.
To Make Corrections
Rotate and push the Wheel to select the incorrect CATV or TV
CH number. Then, Push CLEAR to delete the numbers.
Now, use the Wheel to re-enter the channel.
Push MENU
twice to exit the
VCR Plus+ CH
SET UP mode.
MENU
Make your entries wthin 60 seconds or the VCR will
leave this mode.
Once local channels have been programmed, they will
stay in memory, even in the case of a power failure.
21
