Panasonic PV C1322 - Manual (Page 4)

nit Information
Head Cleaning Specifications
VIDEO HEADS MAV
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
on REFER TO MANUAL
END:PLAY KEY
Playing older or damaged tapes may eventually
cause video heads to become clogged.
Head Clog Sensor
During playback this screen
appears If clogging is
detected. To remove screen,
press PLAY on the remote
or unit.
• Use “dry" type head
cleaning cassette only.
(Part No. NV-TCL30PT is recommended.)
• Follow cleaning tape directions carefully.
Excessive use of head cleaning tape can
shorten the video head life.
• If head dog symptoms persist, contact ycwr
nearest Factory Service Center or authorized
Service Center. (See Page 34.)
Features for a Quality Picture
Digital Auto Tracking
Continuously analyzes the signal and adjusts for
optimum picture quality.
Manual Tracking Control ftp reduce picture noise)
Use during Playback and Slow Motion mode to
reduce picture noise. Press the 3 or 6 number key on
the remote control or CH AT on the unit until the
picture clears up. To return to Auto Tracking, press
POWER off, then on again a few seconds later.
V-Lock Control
In Still mode, the 3 or 6 number key on the remote
control or CH AT on the unit on the unit operate as
a V-lock control to reduce jitter.
Display
Picture Tube:
VCR
Video Recording
System:
13 inch measured diagonal
90“ deflection Picture Tube
2 rota^ heads helical
scanning system
(PV-C1322/PV-C1332W)
4 rotary heads helical
scanning system
(P V-C1342/P V-C1352W)
1 track
VHF2- 13. UHF 14-69
Midband A through I (14 ~ 22)
Superband J through W (23 ~ 36
Hyperband AA ~ EEE (37 ~ 64)
Lowband A-5 - A-1 (95 ~ 99)
Special CABLE channel 5A(01)
Ultraband 65 ~ 94, 100- 125
87.5 * 108.1 Mhz
120 V AC, 60 Hz
Power On
Approx. 69 watts
Power.Qff
Approx. 2.5 watts
Television System: EIA Standard NTSC color
Speaker: 1 piece
Operating Temperature; 5 “C - 40 “C (41 “F -104 “F)
Curating Humidity:
10 % - 75 %
Weight: 12 Kg (26.4 lbs.)
Dimensions: 386 (W) X 385 (H) X 374 (D) mm
15-3/16” (W) X IS-S/lff" (H)
X 14-3/4" (D)
Note; Designs and specifications are subject to change
without notice.
Audio Track;
Tuner
Broadcast Channels:
CABLE Channels:
FM Radio
Band Range:
General
Power Source:
Power Consumption:
Record/Playback Time
Only use tapes with the IVHSI mark in this unit.
Tape Speed
Setting
Type of Video Cassette
T60 T120 T160
SP (Standard Play) 1 Hour 2 Hour
2 Hours
40Mhutes
LP (Long Play) 2 Hours 41-tours
5 Hours
20 Minutes
SLP(SuperLong Play)3 Hours 6 Hours 8 Hours
DST (Daylight Saving Time)
Unit auto adjusts dock for DST (Daylight Saving Time.]
■ Spring (First Sunday in Aprii)
DST ; ON => Sets clock ahead one hour.
■ Autumn (Last Sunday in October)
DST : ON => Turns clock back one hour.
• If your area does not observe Daylight Saving
Time, select DST:OFF.
• Keep these time changes in mind when
programming the unit for timer recordings.
Forassistance, please call: 1-800-211-PANA(7262) orsend e-mail to: consumerproducts® panasonic.com
