94 Leica mojoRTK, Normal System Operation
6.8 Setting the Field Offset Manually

The field offset is used to move the original AB line to a new desired location. This
will be used most often if the base station has been moved. The field offset can be
manually set or automatically set. This section describes the manual setting.
Setting field offset
manually, step-by-
step
1. From the main steering screen, press to enter the main menu.
2. Turn the main dial to select Settings, and then press .
3. Use the main dial to select Guidance, and then press .
4. Use the main dial to select Field Offset. The current offset is shown on the right
side of the screen. Press to change the field offset.
5. Use or the main dial to set a new field
offset.
S_mojoRTK_047
Field Offset
1 .00m
