Leica mojoRTK, Running the mojoRTK Console for the First Time 69
7. Use the main dial to select the vehicle type or
steer kit for your installation and press . You
should see a message stating the steer kit
communications status, for example CAN Bus
Connected, Steering Kit Active.

There may be extra steps required at this point or even later depending on
which vehicle type or steer kit you select.
8. The next screen explains that you are about to enter the Antenna Separation.
Make sure that you have measured the distance between the center of the black
and the red GPS antenna accurately. Refer to "Position of the GPS antennas",
page 27. Press to continue.

Measure from the molded dot in the center on the antenna.
S_mojoRTK_013
OK
Vehicle Type
Select vehicle type
None
