64 Leica mojoRTK, Running the mojoRTK Console for the First Time
4.3 Vehicle Wizard
Vehicle Wizard,
step-by-step 1. The Vehicle Wizard starts with the mojoRTK orientation. The mojoRTK orientation
describes the orientation of the console in the tractor.

For the tests that follow, you will need to drive the tractor and be in an open area
with room to move.
Press and adjust the number to
represent how the system is mounted
in the cab.
If the system is mounted directly in
front of you (when sitting in the
seat), the setting should be 0°. If the
unit is at 90° on your right, then the
setting is 90. If the unit is at 90° on
your left-hand side, then the value is
-90°. Press when you have
entered the correct value.
mojoRTK_010
0°
90°
-90°
