Leica mojoRTK, System Overview

23

1.6

mojoRTK Base Station

Base station over-
view

a) Whip antenna
b) Keyboard and display
c)

USB Port and protection cap

d) Charger connector
e) Accessories connector

f)

Cover for interfaces

g) Cover for battery compartment
h) Battery GEB221, 2 x
i)

Thread for tripod screw

a

b

mojoRTK_022

ESC

Power

Charge

OK

c

d
e

i

f

h

g
