20 Leica mojoRTK, System Overview
Icon description
Icon Description
Base station Icon • A solid icon with three bars means you
have an excellent signal from the base
station.
• A solid icon with two bars means you
have a good signal from the base station.
• A solid icon with one bar means you have
a poor signal from the base station.
• A flashing icon with an X means the
system is trying to lock on to the base
station signal.
GPS Satellites /
Signal Strength • A solid satellite icon with three bars
means you have an excellent signal.
• A solid satellite icon with two bars means
you have a good signal.
• A solid satellite icon with one bar means
you have a poor signal.
• A flashing satellite icon means the
system is not seeing enough satellites.
Accuracy to
Working Line • This icon shows the accuracy of the
system relative to the current working
line while in motion.
