Leica mojoRTK, Normal System Operation 87
6.3 Setting the Line Spacing
General informa-
tion The line spacing sets how far apart the working lines are. This distance is essentially
the width of the implement you are using.
Setting line
spacing, step-by-
step
1. From the main navigation screen, press to enter the main menu and select
Line Spacing by pressing .
2. If measurement is correct as it is, press .
3. Use or the main dial to set the line
spacing according to the measured implement
width - from end tool to end tool.
Once you have set the whole units to the desired
value press , this will then allow you to
change the fractional units (after the decimal
point).
4. Press to confirm the new setting.
S_mojoRTK_027
Line Spacing
12 .00m
