EdgeAccess Universal Chassis System
Model 9135 10/100/1000 3-4
Table 7. System Menu Options
Menu Item Description
1. IP Settings Set the IP parameters
2. Host Table / SNMP Settings Set up the Host Table and SNMP access
3. SLIP Port Settings
Set up for Serial Line Interface Port (SLIP) access
4. Passwords Set passwords for supervisor, manager, and user levels
5. Network Name At the prompt, set the name of the network where the
9135 resides
6. Main Menu Return to the Main Menu
3.4.1 IP Settings
Use the IP Settings menu to view and update the IP parameters and configuration for the 9135. To
access the IP Settings menu, see Figure 9 and Table 8 and follow these steps:
1. From the System Menu, type
2
, IP Settings, and press .
2. At the prompt, type the number for a parameter, follow the prompts to update it, then press
to confirm it. For details, see Table .
IP Settings
Local MAC Address : 00 40 2A 00 53 D1
1. Local IP Address : 172.16.142.74
2. Gateway IP Address : 172.16.1.1
3. Subnet Mask : 255.255.0.0
4. Aging time : 300
5. Enable Download : TFTP and FTP
6. Enable BOOTP Mode : no
7. Management VLAN Number : 1
8. Management VLAN Enabled : no
9. Static ARP Table
10. Dynamic ARP Table
11. Main Menu
Figure 9. IP Settings
