EdgeAccess Universal Chassis System
L357 Gigabit Ethernet Service Unit 4-23
4.11 Utilities
Use the Utilities screen to set the time and date, reset a configuration, or enable or disable the remote
console port. See Figure 36 and Table 10. To access the Utilities screen, follow this step:
1. From the Main Menu, type 6 , "Utilities," and press . The Utilities menu appears.
2. To return to the Main Menu, press .
UTILITIES
1) Set Date and Time
2) Reset Configuration To Default
3) Reset Remote Configuration To Default
4) Remote Craft Port: Enabled
5) Modem/Slip/PPP Baud Rate 19200
6) Modem Initialization String AT
7) PING generation
8) Static ARP Table
9) Dynamic ARP Table
Figure 36. Utilities Menu Screen
Table 10. Utilities Menu Options
Item Definition
1) Set Date and Time Change the time and date information for the modem if
needed; if in a chassis with a DMM, the DMM date and
time overrides the L357
2) Reset Configuration To Default
3) Reset Remote Configuration To
Default Restores all configurable settings to the defaults except for:
date and time; password; BOOTP; Telnet timeout
4) Remote Craft Port Enable or disable the console port on the remote module
5) Modem/Slip/PPP Baud Rate Select the baud rate, 9600, 19200, 38400, 57600, or
115200 bps for the modem/SLIP/PPP serial port (standalone
enclosure, only)
6) Modem Initialization String The default string is "AT" (standalone enclosure, only)
7) PING Generation Access the PING diagnostics screen (standalone enclosure,
only)
8) Static ARP Table Set or change specific IP and MAC addresses (standalone
enclosure, only)
9) Dynamic ARP Table View current IP and MAC addresses (standalone enclosure,
only)
