FaxBack Port Server RADIUS Support (RFC 2865, 2866) - Manual (Page 28)

FaxBack Proprietary and Confidential Page 28 of 58
◄── RESPONSE TO PORT SERVER ───
Required Purpose
RADIUS code Access-Accept or Access-Reject
Optional Purpose
User-Name Specifies the name of the account that the input ANI (caller Id) from
the request packet mapped to.
FB-Queue-Profile An optional Queue Profile to be used for later processing of the send
fax. The returned queue profile XML must include the attribute
Op=”1”, to cause the DID-level queue profile to override the account-
level queue profile. For example,
Language and time zone information do not need to be included, as
these values are specified at the account level. If there are included
in the XML returned from a Get-DID request, they will be ignored.
FB-Snd-ANI An optional override of the ANI (caller Id) for later processing of the
send fax.
FB-Line-Num Physical line number that maps to the DID.
FB-Line-Id A name or description to associated with the DID or fax ATA line.
Response Packet
Code=Access-Accept(2)
Packet identifier=8
Length=47
Authenticator
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Attributes:
Len=9, Type=User-Name(1)
Value=testata
Len=18, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=12, Type=FB-Snd-ANI(19)
Value=5551119999
End
Get-DIDs-For-Account / For-External-Module
Sent from the port server when an external component, such as a fax ATA provisioning server,
requires the list of all DIDs associated with an account.
Support for this command is optional at the RADIUS server. The only time the port server
requests this information is for provisioning of fax ATAs.
─── SENT FROM PORT SERVER ──►
Attribute Value
FB-Command Get-DID (8)
FB-Context For-Extermal-Module (5)
User-Name Locate all DIDs mapped to this account.
