FaxBack Proprietary and Confidential Page 27 of 58
Language and time zone information do not need to be included, as
these values are specified at the account level. If there are included
in the XML returned from a Get-DID request, they will be ignored.
FB-Snd-ANI An optional override of the ANI (caller Id) for later processing of the
send fax.
Response Packet
Code=Access-Accept(2)
Packet identifier=8
Length=47
Authenticator
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Attributes:
Len=9, Type=User-Name(1)
Value=testata
Len=18, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=12, Type=FB-Snd-ANI(19)
Value=5551119999
End
Get-DID / For-External-Module
Sent from the port server when an external component, such as a fax ATA provisioning server,
requires configuration information specific to a DID.
Support for this command is optional at the RADIUS server. The only time the port server
requests this information is for provisioning of fax ATAs.
─── SENT FROM PORT SERVER ──►
Attribute Value
FB-Command Get-DID (8)
FB-Context Pre-Send-Session (3)
User-Name The DID to lookup.
Request Packet
Code=Access-Request(1)
Packet identifier=1
Length=62
Authenticator
4C BF 52 6E 51 18 D9 4E 88 35 19 B9 93 D5 11 33
Attributes:
Len=18, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=6, Type=FB-Command(1)
Value=Get-DID(8)
Len=6, Type=FB-Context(2)
Value=Pre-Send-Session(3)
Len=6, Type=User-Name(1)
Value=2222
End
