FaxBack Port Server RADIUS Support (RFC 2865, 2866) - Manual (Page 25)

FaxBack Proprietary and Confidential Page 25 of 58
Attribute Value
FB-Command Get-Account-From-Sender-Email-Address (3)
FB-Context For-External-Module (5)
User-Name The sender e-mail address to match to an account
Request Packet
Code=Access-Request(1)
Packet identifier=49
Length=63
Authenticator
E6 64 28 E2 03 8D 36 41 8A 2B 8F E1 79 51 08 79
Attributes:
Len=18, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=6, Type=FB-Command(1)
Value=Get-Account-From-Sender-Email-Address(3)
Len=6, Type=FB-Context(2)
Value=For-External-Module(5)
Len=25, Type=User-Name(1)
[email protected]
End
◄── RESPONSE TO PORT SERVER ───
Required Purpose
RADIUS code Access-Accept or Access-Reject
User-Name Account that matched the input sender e-mail address
Optional Purpose
FB-Snd-From-Account Determines if the known/valid account is enabled for send.
Response Packet
Code=Access-Accept(2)
Packet identifier=49
Length=29
Authenticator
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Attributes:
Len=9, Type=User-Name(1)
Value=account
End
Get-DID / Pre-Send-Session
Sent from the port server when a fax ATA is sending a fax (uploading via HTTPS), to retrieve
settings that are associated with the line on the ATA. The request from the port server will
include the ANI (caller Id) of the send call in the User-Name attribute, which can be used by the
RADIUS server to query for a matching DID or line record. The RADIUS server can return FB-
Queue-Profile and/or FB-Snd-ANI attributes that will be used by the port server for the remainder
of the fax session.
Support for this feature at the RADIUS server is optional.
