FaxBack Port Server RADIUS Support (RFC 2865, 2866) - Manual (Page 20)

FaxBack Proprietary and Confidential Page 20 of 58
The RADIUS server must respond with an Access-Accept packet that includes an e-mail address
in the “FB-Rcv-Email” attribute for the recipient of the e-mail message, or an Access-Reject
packet if routing to the DID was not possible.
─── SENT FROM PORT SERVER ──►
Attribute Value
FB-Command Get-Account-From-DID (2)
FB-Context For-External-Module (5)
User-Name The DID to match to an account
Request Packet
Code=Access-Request(1)
Packet identifier=77
Length=76
Authenticator
3C 24 7E 06 C0 9D 4D 42 BE 1E 01 35 DB B7 6C FC
Attributes:
Len=18, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=6, Type=FB-Command(1)
Value=Get-Account-From-DID(2)
Len=6, Type=FB-Context(2)
Value=For-External-Module(5)
Len=12, Type=User-Name(1)
Value=5551231234
End
◄── RESPONSE TO PORT SERVER ───
Required Purpose
RADIUS code Access-Accept or Access-Reject
User-Name Account that matched the input DID
Optional Purpose
FB-DID-Enabled Determines if the known/valid DID is enabled for receive.
Response Packet
Code=Access-Accept(2)
Packet identifier=77
Length=53
Authenticator
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Attributes:
Len=9, Type=User-Name(1)
Value=account
Len=24, Type=Vendor-Specific(26), Id=FaxBack(30694)
Len=18, Type=FB-Rcv-Email(14)
[email protected]
End
Get-Account-From-MAC-Address / For-External-Module
