OFNA Racing JL10e User Manual

Page 6

ASSEMBLY OF THE FRONT SUSPENSION ARMS

ASSEMBLY OF THE SUPR GEAR AND THE DIFF. MOTOR MOUNT

ASSEMBLY OF THE REAR GEAR BOX

Assemble both right and left sides

90020
2.5mm E-Ring

.....x1

37151
2x7.8mm Pin

.....x3

3x5mm

37151

37430

37147

37430

37136

37139

3x5mm

2.5mm

37500

37148

37149

37142

37430
5x11mm Ball Bearing

.....x2

94001
3x5mm Screw

.....x2

37149
8x1.5mm O-Ring

.....x1

38254
12x15x0.25mm Shim

.....x2

.....x4

94050
2.6x10mm
Cap Screw

2.6x10mm

38254

3x15mm

E-69

37170

94005
3x15mm
Screw

.....x2

*Adjust the backlash with the shims.

*Snap onto knuckle arm.

Apply
Grease

*Assembly the front rod to shock tower as picture shown.

37147

*check correct holes

before

assembling

the spur gear.
*Use the metric holes

for this

kit.

Metric

Imperial

37147

Insert the 2mm pin
before assemble
the O-ring.

Do Not
Over Tighten
