Page 12

ASSEMBLY OF THE FRONT BUMPER AND FOAM BUMPER

INSERT BATTERY INTO BATTERY HOLDER

87660

ASSEMBLY OF THE TIRES AND WHEELS

87917

87660

87917

94004
3x12mm
Screw

.....x2

94002
3x8mm
Screw

.....x1

94021
3x15mm
Flat Head Screw

.....x1

3x8mm

3x12mm

3x15mm

38294

Step 2

Step 1

3x12mm

94019
3x10mm
Flat Head Screw

.....x2

3x10mm

Step 2

Step 1

Step 3

Step 1

Step 2

*Make two left tires are the same.

* Notice the direction
of the tires.

*Make two right tires are the same.

* Notice the direction
of the tires.

*Pull back the tire bead slightly and spot

glue in four spots as shown. When dry, glue

the rest of the wheel between the spots.

Repeat the procedure on the other side of

the wheel until fully glued.

Contact
Adhesive

38291

7,4V Battery Pack

(

)

Not included

*To the hole on the
top of gear box.

*Remove the screw and
turn the battery cover
as picture shown.

3 X10mm
Screw

Rotate
Direction
