OFNA Racing JL10e User Manual
Page 14
36
Step 1
Step 2
Step 3
Do Not
Over Tighten
*Take off the paper from
double side tape before
assembly.
Side Plate
Side Plate
Side Plate
Double side
Tape
Double side
Tape
Cut Out
Cut Out
37410
37410
37410
37410
34
35
ASSEMBLY OF THE WING
36
MOUNTING BODY
94002
3x8mm
Screw
.....x2
3x8mm
Spray Paint
Nylon Nut
Body Reamer
(Not included)
*Use body reamer or
tool to make a 3mm
hole as Picture Shown.
* paint the color to the
rear wing from back side.
