OFNA Racing JL10e User Manual

Page 5

background image

10

11

12

ASSEMBLY OF THE KNUCKLE ARMS

Assemble both right and left sides.

ASSEMBLY OF THE KNUCKLE ARMS AND FRONT LOWER ARMS

ASSEMBLY OF THE FRONT BLOCK ONTO CHASSIS

94035
3x8mm
Set Screw

.....x2

.....x2

30403
6mm Ball

Step 2

Step 1

94002
3x8mm
Screw

.....x4

*Approx. 9mm

1:1

Step 2

Step 1

37430

37430

37181

37640

37590

37220

37220

37360

4mm Ball&Socket

.....x2

3x8mm

3x8mm

37360

37390
2x10.8mm Pin

.....x2

37550

37390

.....x2

37370
6mm Ball and Socket

3x12mm

37370

30403

38398 (3x20mm)

37201

3x8mm

37100 (Short)

37100 (Long)

94004
3x12mm
Screw

.....x2

.....x2

94019
3x10mm
Flat Head Screw

.....x2

3x10mm

3x10mm

38262 (3x50mm)

38262
3x50mm Arm Shaft

.....x2

Assemble both right and left sides.

*Approx. 3.4mm

*A 3x8mm set screw is used
to adjust ride-height.

37430
5x11mm Ball Bearing

.....x4

37220
Knuckle Arm Bushing

38263

Assemble both right and left sides.

Use the 1.5 degree for
front lower arm holder.

37201
3x25mm Screw Type Arm Shaft (Black)

Ensure
Free
Movement
