OFNA Racing Jammin X1 CRT RTR - Manual (Page 22)

47
17
Step 1
Step 2
..........X1
ASSEMBLY OF THE REAR SHOCKS ONTO SHOCK STAY
48
40127
Air Filter
Cap
40128
Air Filter
foam
40127
Air Filter
Mount
40129
Air Filter
Connector
49
ASSEMBLY OF THE AIR FILTER
3x8mm
Hex Screw
Nylon Strap
(Small)
Apply filter oil to the
foam before use.
94002
3x8mm
Hex Screw
94007
3x20mm
Hex Screw
..........X2
94041
3mm
Nylck Nut
3x8mm
Washer
40643
Shock Cap
Bush
..........X2
..........X2
..........X2
3x8mm
Washer
94041
3mm
Nylock Nut
40643
Shock Cap
Bush
94007
3x20mm
Hex Screw
Step 1
Nylon Strap
(Small)
Step 2
..........X3
94004
3x12mm
Hex Screw
94003
3x10mm
Hex Screw
..........X6
ASSEMBLY OF THE FRONT BUMPER
94004
3x12mm
Hex Screw
3x10mm
Hex Screw
94003
3x10mm
Hex Screw
94003
3x10mm
Hex Screw
94004
3x12mm
Hex Screw
40669
Front
Bumper(B)
40669
Front
Bumper(A)
40669
Front
Bumper(C)
40669
Front
Bumper(D)
94027
4x16mm
Flat Head
Hex Screw
..........X2
94027
4x16mm
Flat Head
Hex Screw
Assembly both left and right hand side.
