OFNA Racing Jammin X1 CRT RTR - Manual (Page 10)

5
Step 1 Step 2
15
40539
6x10mm
Plastic Bushing
40539
6x10mm
Plastic Bushing
X1-39
Servo Saver
Horn C
40511
Servo Saver
Post
ASSEMBL OF THE SERVO SAVER Y
94009
4x10mm
Hex Screw
94004
3x12mm
Hex Screw
94009
4x10mm
Hex Screw
94004
3x12mm
Hex Screw
94009
4x10mm
Hex Screw
40505
Gray
Front Plate
..........X2
..........X2
..........X4
..........X1
94041
3mm
Nylock Nut
94041
M3
Nylock Nut
94041
M3
Nylock Nut
40676
Center
Bracer (Front)
Step 1 Step 2
40507
Alum Servo Saver
Connecting Plate
40039
4x8mm
Plastic Flange
Bushing
40039
4x8mm
Plastic Flange
Bushing
40037
Steering Plat
Hex Screw
40037
Steering Plat
Hex Screw
40037
Steering Plat
Hex Screw
14 ASSEMBL OF THE SERVO SAVER Y
40539
Servo Saver
Horn A
40039
Servo Saver
Horn C
40563
Servo Saver
Tube
40539
Servo Saver
Horn B
40500
Servo Saver
Spring (Black)
40034
Servo Saver
Spring Tension
Adjuster
..........X4
..........X4
..........X2
..........X2
13 ASSEMBL OF THE FRONT STABILIZER Y
40584
Front Stabilizer
2.5mm 94002
3x8mm
Hex Screw
94002
3x8mm
Hex Screw
40533
Stabilizer
Mount Plastic
94033
M3x3
Set Screw
94033
M3x3
Set Screw
94033
M3x3
Set Screw
94033
M3x3
Set Screw
40024
13x16x0.2mm
Shim
..........X2
40024
13x16x0.2mm
Shim
40024
13x16x0.2mm
Shim
40539
6x10mm
PlasticlBushing
40539
6x10mm
Plastic Bushing
40539
6x10mm
Plastic Bushing
40039
4x8mm
Plastic Flange
Bushing
* Notice the direction of the servo saver connecting plate.
* Take the plastic busing
from 40539 plastic tree.
