OFNA Racing Jammin X1 CRT RTR - Manual (Page 19)

10114
5mm
Engine Mount
Screw
10114
5mm x 10mm
Engine Mount
Screw
39
38
Step 1
Step 2
..........X1
..........X1
..........X4
..........X1
95700
1/8 Silicone
Seal
ASSEMBL OF THE MANIFOLD AND MUFFLER Y
ASSEMBLY OF THE ENGINE ONTO CHASSIS
Spur Gear
Clutch Bell
Loose or tighten 3x12mm cap screw
and 5x10mm engine mount screw to
align spur gear and clutch bell gear to
90 degree.
90 degree
94026
4x10mm
Flat Head
Hex Screw
94026
4x10mm
Flat Head
Hex Screw
94036
5x4mm
Set Screw
94034
4x4mm
Set Screw
Use note book paper to set gear backlash
between spur gear and clutch bell gear,
applying pressure while retightening the
engine.
If the space is not correct the spur gear
will be damaged.
94036
5x4mm
Set Screw
94034
4x4mm
Set Screw
31991
Manifold
40050
Muffler Stay
Post
40559
Muffler Stay
Nylon Straps
(Middle)
31992
Muffler
10184
Sillcone Tube
10120
Manifold
Spring
40
14
Step 1 Step 2
..........X2
..........X2
..........X1
..........X2
94033
3x3mm
Set Screw
30801
Adjust Mount
30801
Adjust Mount
30801
Servo
Mount
10768
Servo Horn
94033
3x3mm
Set Screw
36140
2mm
Adjust nut
30801
2mm
Adjust Mourt
40663
2X68mm
Brake Rod
ASSEMBLY OF THE THROTTLE LINKAGE
30801
2X8mm
Screw
30801
2.6x18mm
Screw
30801
2mm Nut
30801
2.5mm
Nylock Nut
30801
2.5mm
Nylon Nut
Cut off the servo saver as shown.
30801
2mm Nut
30801
2X8mm
Screw
30801
2.6X18mm
Screw
..........X2
..........X1
*Adjust the height with
3 x 6.4 x1mm washer.
40663
2X68mm
Brake Rod 30801
3x6.4x1mm Washer
