OFNA Racing Jammin SCRT Nitro RTR User Manual

Page 31

background image

49

51

ASSEMBLY OF THE MANIFOLD AND MUFFLER

ASSEMBLY OF THE THROTTLE LINKAGES INTO LEVER

17

50

ASSEMBLY OF THE THROTTLE LINKAGE

94018
3x5mm
Flat Head Hex Screw

.....x1

94034
4x4mm
Set Screw

.....x1

94036
5x4mm
Set Screw

.....x1

40917

38397

Zip tie

40968

3x5mm

4x4mm

5x4mm

10120

40832

95901

Step 1

Step 2

94033
3x3mm
Set Screw

.....x4

40060
2.5mm Nylon Nut

.....x1

30801
2.6X18mm
Screw

.....x1

94003
3x10mm
Screw

.....x1

Step 1

Step 2

30172

40967

30800

2.6x18mm

30800

3x10mm

10300

3x3mm

30172

30800

30531

94033
3x3mm
Set Screw

.....x2

10300

3x3mm

36140

Use the screw provided with
your servo .

2.5mm Nylon Nut

40970
