OFNA Racing Jammin SCRT Nitro RTR User Manual

Page 28

background image

40

41

42

ASSEMBLY OF THE FRONT STEERING SERVO

ASSEMBLY OF THE STEERING TIE-ROD

ASSEMBLY OF THE STEERING ROD AND RADIO TRAY

94005
3x16mm
Hex Screw

.....x4

Approx. 31.9mm

37381

37381

30400 (3x46mm)

Step 1

Step 2

94040
3x8mm Washer

.....x4

3x16mm

3x8mm

34026

34026

STEERING SERVO

37360

Use the screw provided with
your servo .

40967

2x8mm
Screw

.....x4

94002
3x8mm
Hex Screw

.....x5

94004
3x12mm
Hex Screw

.....x4

.....x4

94040
3x8mm Washer

Step 2

2x8mm

40541

40541

Step 1

10282

•Connect the switch wire
to receiver.

40541

•Use the screws provided
with your switch

Switch

34026

40541

40541

3x12mm

3x8mm

3x8mm

SERVO

40504
