OFNA Racing Jammin SCRT Nitro RTR User Manual

Page 24

background image

28

30

ASSEMBLY OF THE REAR BODY POST

ASSEMBLY OF THE REAR BUMPER

29

ASSEMBLY OF THE REAR BODY STAY ONTO REAR GEAR CASE

94004
3x12mm
Hex Screw

.....x2

3x12mm

3x12mm

3x16mm

40947

94004
3x12mm
Hex Screw

.....x4

Step 1

Step 2

94041
3mm
Nylon Nut

.....x2

Step 1

Step 2

94005
3x16mm
Hex Screw

.....x2

94054
2.6x15mm
Screw

.....x2

94005
3x16mm
Hex Screw

.....x2

Step 1

Step 2

94021
3x15mm
Flat Head Hex Screw

.....x2

94005
3x16mm
Hex Screw

.....x2

40947

40947

40947

Assemble both right and left sides.

2.6x15mm

94020
3x12mm
Flat Head Hex Screw

.....x2

3mm

3x12mm

3x16mm

3x12mm

3x16mm

3x15mm

40944
