ASSEMBLY OF THE CENTER DIFF.

ASSEMBLY OF THE FRONT GEAR CASE

ASSEMBLY OF THE FRONT SHOCK STAY

Step 1

Step 2

Step 1

Step 2

Step 1

Step 2

.....x8

30779
4x10mm Washer

30773
4mm
Cross Pin

.....x2

Dif . Oil

40011

2.6x10mm

30773

40805

30779

.....x4

Tight the diff screws in this order.

3x35mm

3x10mm

Adjust the backlash with the shims.

Apply
Grease

38254
12x15x0.25mm Shim

.....x2

37430
5x11mm Ball Bearing

.....x2

94043
3x35mm Hex Screw

.....x2

94003
3x10mm Hex Screw

.....x2

3x10mm

94003
3x10mm
Hex Screw

.....x4

Use 1000 weight diff. oil in the
center.
Fill the Diff. Case to approx. 80%
with the Diff.Oil.

38254

40804

37430

40840

40806

4x4mm

40840

40813

40842

3x10mm

40872

94046
2.6x10mm
Flat Head Screw

94034
4x4mm Set Screw

.....x1

1:1

Tighten

* Notice the direction of the
front lower arm holder in front.

Down
