OFNA Racing Jammin CRT .5 Mini User Manual

Page 11

background image

16

17

18

ASSEMBLY OF THE WING STAY

ASSEMBLY OF THE REAR LOWER ARMS

ASSEMBLY OF THE REAR SUSPENSION ARMS

Step 1

Step 2

Assembly for both right and left side.

3x12mm

40834

3x15mm

3x12mm

3x12mm

40816

40837

40825

40836

40837

40836

3x8mm

3x8mm

3x4mm

40823

37430

37430

40843

40840

37390

40875

40843

94004
3x12mm
Hex Screw

.....x3

94005
3x15mm
Hex Screw

.....x1

94035
3x8mm
Set Screw

.....x2

94004
3x12mm
Hex Screw

.....x2

37430
5x11mm Ball Bearing

.....x4

94001
3x4mm
Hex Screw

.....x2

1:1

1:1

37390
2x10.8mm Pin

.....x2

Ensure
Free
Movement

Ensure
Free
Movement

Ensure
Free
Movement

*A 3x8mm set screw is
used to adjust ride-height.
