ASSEMBLY OF THE ENGINE ONTO CHASSIS

ASSEMBLY OF THE MANIFOLD AND MUFFLER

ASSEMBLY OF THE THROTTLE LINKAGE

Step 1

Step 2

Step 1

Step 2

Step 3

Cut off the servo saver as shown.

2mm

30661

2x8mm

30802

3x10mm

2.6x18mm

30802

30531

3x3mm

10300

30802

30172

10300

40829

37100

(1mm)

(2mm)

3x3mm

3x8mm

97501

3x5mm

4x4mm

95700

4x4mm

10120

40831

40832

40878

40879

95901

40060

94002
3x8mm
Hex Screw

.....x4

94018
3x5mm
Flat Head Hex Screw

.....x1

94034
4x4mm
Set Screw

.....x2

94033
3x3mm
Set Screw

.....x2

2mm Nut

.....x2

40060
2.5mm Nylon Nut

.....x1

2X8mm
Screw

2.6X18mm
Screw

.....x2

.....x1

*Use note book paper to set gear backlash
between spur gear and clutch bell gear,
applying pressure while retightening the
engine.
*If the space is not correct the spur gear
will be damaged.

Note book Paper.

Ensure
Free
Movement

*Take the 1mm and 2mm washer
from shock plastic tree.
