MAKING HOLES AND CUTTING ON THE WING

MAKING HOLES AND CUTTING ON THE BODY SHELL

MAKING HOLES AND CUTTING ON THE WING

Before making holes on the body,
put the unpainted body on the chassis
to confirm the mounting position and
location for holes.

Step 1

Step 2

Make 9mm holes on the body shell as shown.

Make 4mm holes

Make 7mm holes

Body Reamer

(not included)

Make a 7mm hole

Make 3mm holes

Make 3mm hole

Make 3mm holes

Make 3mm hole

Wing Side Plate(L)

Wing Side Plate(R)

Step 1

Step 2

The position and the wing is the same.

Hole Position
