17

Step 2

46

ASSEMBLY OF THE REAR BUMPER

4x12mm

.....x2

36870
4x10mm
Set Screw

4x10mm

31159

31159

40117

2.6x15mm

2.6x15mm

94054
2.6x15mm
Screw

.....x2

94026
4x12mm
Flat Head
Hex Screw

.....x2

40721

Tighten

Tighten

Step 1

47

94009
4x10mm
Hex Screw

.....x2

4x10mm

3x12mm

94004
3x12mm
Hex Screw

.....x2

ASSEMBLY OF THE REAR BUMPER

•The 4x10mm set screw is used to adjust down stop.

•Approx. 3 mm

48

40117

40720

40117

40720

BATTERY INSTALL

Battery(Not Included)

8mm

15mm

•If use hard case battery , make a hole as picture shown.

Follow the manual instruction sprovided by ESC
manufacturer to install the wire.

•Be aware of the direction of the battery.

Hard Case Battery
