40

ASSEMBLY OF THE RECEIVER INTO RADIO BOX

94002
3x8mm
Hex Screw

.....x2

Step 2

Step 1

Step 3

30662

3x8mm

Receiver(Not Included)

•Plug in your speed control wire
and servo wire to your receiver.

37410

30662

40642

30560

Antenna Wire

41

42

ASSEMBLY OF THE STEERING ROD ONTO RADIO BOX

•Approx. 16.6mm

94004
3x12mm
Hex Screw

.....x2

0

20

30

40

10

Step 2

Step 1

30411

37320

30401

30401

30411

3x12mm

Use the screw
provided with
your servo.

10769

30661

3x12mm

4x12mm

ASSEMBLY OF THE FRONT BUMPER

40721

40721

94026
4x12mm
Flat Head
Hex Screw

.....x3

.....x2

94020
3x12mm
Flat Head
Hex Screw

3x12mm

Tighten

Tighten

4mm

.....x3

94042
4mm
Nylon Nut

*Approx. 30.5 mm


1:1

40721
