85
ENGLISH
5
Wipe the rollers with a firmly wrung cloth moistened with water or
mild detergent.
Rollers are located at the positions indicated in the figure below. Turn
these rollers in the direction of the arrows as you wipe them clean.
Rollers
• If a roller becomes loose (Figure A), re-attach it as shown in Figure B.
• Before you return the upper unit to its original position, be sure to lower the lever
on the feed unit (Figure B). If the document is scanned with the lever at the up
position, a paper feed error will occur.
6
Use a clean, dry, soft cloth to wipe off any water from the rollers.
5.1 Daily Cleaning
HINT
Roller
A B
1. Fit into the deeper
of the two grooves.
2. Press this part.
3. Lower the lever.
