Chemtronics Chemask Aqua - Water Removable CMAQ1 - Manual

PRODUCT DESCRIPTION
Chemask

Aqua is a high temperature
temporary spot mask that protects
component-free areas from molten solder
during wave soldering. It is water soluble,
designed to be removed with open and
closed loop aqueous cleaning systems.
Chemask

Aqua is low foaming and has no
effect on deionized water (DI) system resin
beds. This water soluble formulation is
stable to rosin, organic and inorganic fluxes.
 Protects boards from molten solder to
515

F (268

C)
 Prolongs deionized water system life
 Low foaming
 Compatible with most flux types
 Leaves no corrosive residue
 Does not contain Methanol
 Non-contaminating
TYPICAL APPLICATIONS
During wave soldering, Chemask

Aqua
Solder Masking Agent protects:
 Component Free Areas
 Gold Connectors
 Gold Fingers
 Pin Connectors
TYPICAL PRODUCT DATA AND
PHYSICAL PROPERTIES
Base Material Synthetic Resin
Color Orange
Flux Compatibility All types
Temperature Stability 515

F (268

C)
Tack-Free Drying Time
(10 mils @ 77

F)
30 min.
Cure Time
(10 mils @ 77

F)
1 hour
Viscosity (@ 77

F) 40,000 cps to 50,000
cps
Viscosity Adjusted With Deionized water
Solids Content ~ 40%
pH 7.0 – 8.0
Weight/Gallon 9.1 lbs.
Shelflife 1 year
COMPATIBILITY
Chemask

Aqua Solder Masking Agent is
generally compatible with most materials
used in printed circuit board fabrication. As
with
any solder masking agent,
compatibility with substrate must be
determined on a non-critical area prior to
use.
TDS # CMAQ
CHEMTRONICS
Technical Data Sheet
Chemask

Aqua
