Grading Obstruction Overlay
The overlay is used to judge the size any particles or scratches are in the grading zones. The
zones are based on specification IEC-61300-3.
Clicking the Show Grading button will display grading circles as illustrated below. The overlay
can be moved by clicking and dragging on the top bar of the overlay.
Figure 17: Sample Obstruction Overlay
