USAGE INSTRUCTIONS
For industrial use only.
Read MSDS carefully prior to use.
1) Choose a Soder-Wick
Lead-Free braid width
equal to or slightly larger than the pad or
connection.
2) Choose a solder iron tip equal to or slightly
larger than the pad or connection.
3) Set temperature of iron between 650
° and 750°F
4) Place wick on solder joint or pad and place tip
of hot iron on top of wick
5) As solder becomes molten, the color of the wick
will change from copper to silver.
6) Remove wick and iron simultaneously once
color change has stopped.
7) The component lead / pad is now clean and free
from solder.
8) Clip and discard the used portion of the wick.
9) If needed, clean PCB with CircuitWorks
Lead-
Free Flux Remover Pen CW9400 and remove
soils with a ControlWipes
absorbent wipe.
SODER-WICK
IS DESIGNED TO MEET
OR EXCEED THE FOLLOWING:
MIL-F-14256F, Type R
NASA-STD-8739.3
DOD-STD-883E, Method 2022
ANSI/IPC J STD-004, Type ROL0
BELLCORE TR-NWT-000078
ANSI/IPC J SF-818
SODER-WICK
SD BOBBINS ARE
DESIGNED TO MEET OR EXCEED:
MIL-STD-2000A
MIL-B-81705C
MIL-STD-1686C
MIL-HDBK-263B
TECHNICAL & APPLICATION
ASSISTANCE
Chemtronics provides a technical hotline to
answer your technical and application
related questions. The toll free number is:
1-800-TECH-401.
AVAILABILITY
40 Series Lead-Free No Clean Flux
25 bobbins / bag
Part #
Size
5 feet
10 feet
40-2-5
40-2-10
2
40-3-5
40-3-10
3
40-4-5
40-4-10
4
VacuPak
Packaging
Part #
Size
The VacuPak
Can contains ten
five-foot bobbins in a vacuum
sealed can. This package
provides the highest level of
cleanliness and freshness. Great
for tool kit storage.
SW14025
2
SW14035
3
SW14045
4
NOTE:
This information is believed to be accurate. It
is intended for professional end users having the skills to
evaluate and use the data properly. CHEMTRONICS
does not guarantee the accuracy of the data and assumes
no liability in connection with damages incurred while
using it.
Chemtronics
8125 Cobb Center Drive
Kennesaw, GA 30152
1-770-424-4888
REV. A (02/05)
Chemtronics
, Soder-Wick and CircuitWorks are
registered trademarks of Chemtronics. All rights reserved.
Vacu-Pak
and ControlWipes are trademarks of
Chemtronics. All rights reserved.
DISTRIBUTED BY:
