Part # Size Inches Color Size Metric
1 .030” White .76mm
2 .060” Yellow 1.52mm
3 .080” Green 2.03mm
4 .110” Blue 2.79mm
5 .145” Brown 3.68mm
6 .210” Red 5.33mm
BGA - Purple -
USAGE INSTRUCTIONS
For industrial use only.
Read MSDS carefully prior to use.
1) Choose a Soder-Wick

No Clean width equal to
or slightly larger than the pad or connection.
2) Choose a solder iron tip equal to or slightly
larger than the pad or connection.
3) Set temperature of iron between 600-750
°F.
4) Place wick on solder joint and place tip of hot
iron on top of wick.
5) As solder becomes molten, the color of the wick
will change from copper to silver.
6) Remove wick and iron from joint
simultaneously once color change has stopped.
7) The component lead / pad is now clean and free
from solder.
8) Clip and discard used portion of the wick.
TECHNICAL & APPLICATION
ASSISTANCE
Chemtronics provides a technical hotline to
answer your technical and application
related questions. The toll free number is:
1-800-TECH-401.
Chemtronics
, Soder-Wick and CircuitWorks are
registered trademarks of Chemtronics. All rights reserved.
VacuPak
 is a trademark of Chemtronics. All rights reserved.
AVAILABILITY
Part # Size Length Part # Size Length
60-1-5 1 5 60-1-10 1 10
60-2-5 2 5 60-2-10 2 10
60-3-5 3 5 60-3-10 3 10
60-4-5 4 5 60-4-10 4 10
60-5-5 5 5 60-5-10 5 10
60-6-5 6 5
VacuPak

Packaging Part # Size
The VacuPak

Can contains
ten five-foot bobbins in a
vacuum sealed can. This
package provides the highest
level of cleanliness and
freshness. Great for tool kit
storage.
SW16015 1
SW16025 2
SW16035 3
SW16045 4
SW16055 5
SW160BGA BGA
NOTE:
This information is believed to be accurate. It is
intended for professional end users having the skills
to evaluate and use the data properly. Chemtronics
does not guarantee the accuracy of the data and
assumes no liability in connection with damages
incurred while using it.
CHEMTRONICS
8125 COBB CENTER DRIVE
KENNESAW, GA 30152
1-770-424-4888
REV. F (08/13)
