COMPATIBILITY

CircuitWorks

Conductive Epoxy is

generally compatible with most materials
used in printed circuit board fabrication. As
with any adhesive/sealant, compatibility
with substrate should be determined on a
non-critical area prior to use.

USAGE INSTRUCTIONS

Read MSDS carefully prior to use.

Cleaning: For best results, clean the board
with one of Chemtronics

Electro-Wash

or

Pow-R-Wash

cleaners in order to remove

any surface contamination which may
prevent adequate material contact.

Mixing: Mix equal amounts (1:1) by
weight or volume of Part A and Part B. Mix
thoroughly for 2 minutes and apply within 8
minutes.

Thinning: Do not attempt to thin.

Curing: Curing times and electrical
conductivity depend primarily on
temperature. For fastest curing times,
maximum conductivity and adhesion, cure
the bond between 150-250

°F (65-121°C) for

5-10 minutes. CircuitWorks

Conductive

Epoxy can be room temperature cured at or
above 75

°F (25°C), for 4 hours. Maximum

conductivity and bond strength are achieved
in 24 hours. Curing at temperatures below
75

°

F (25

°C) will result in a loss of

conductivity and adhesion.

Pot Life:
8-10 Minutes at 75

°F (25°C) after

mixing.




AVAILABILITY

CW2400

7g/ 0.25 oz. Adhesive &

7g/ 0.25 oz. Hardener


CW2400J

10g/ 0.35 oz. Adhesive &

10g/ 035 oz. Hardener

TECHNICAL & APPLICATION
ASSISTANCE

Chemtronics provides a technical hotline to answer
your technical and application related questions.
The toll free number is: 1-800-TECH-401.


NOTE:

This information is believed to be accurate. It is
intended for professional end users having the skills
to evaluate and use the data properly.

CHEMTRONICS does not guarantee the accuracy
of the data and assumes no liability in connection
with damages incurred while using it.



CHEMTRONICS
8125 COBB CENTER DRIVE
KENNESAW, GA 30152
1-770-424-4888

REV. K (08/13)
