MAXIM 3000® UNIT ACCESSORY LOCATIONS
The following will be the standard locations for accessories when assembled by Satellite Industries
Location
“A” PAPERGUARD
Right panel, see
Maxim 3000 unit
assembly instructions
P/N 17674. 2 PAPERGUARD PER UNIT
Right panel, mount lower
paperguard see unit assembly
instructions P/N 17674. Mount
upper paperguard 2 ¼” directly
above lower paperguard. 3 ROLL PAPERGUARD Right
panel, see 3 roll paperguard
installation instructions P/N
18142
Location
“B” PAPERGUARD WITH HANDWASH
MAX3000
Left panel, SEE UNIT ASSEMBLY
INSTRUCTIONS P/N 17674. PAPERGUARDS /2 PER UNIT WITH MAX3000
HANDWASH. Mount lower paperguard in the
same location as unit with HANDWASH MAX
3000 with single paperguard. Mount upper
paperguard 2” directly above lower
paperguard.
Location
“B” 3 ROLL PAPERGUARD / WITH
MAX3000 HANDWASH
Right panel, see 3 roll paperguard
installation instructions P/N 18142
#19234 Rev, A 1 8/06
