Cisco 700 MHz User Manual
Page 58
2-34
Installation and Upgrade Guide for Cisco Unified MeetingPlace Audio Server 6.x
OL-13417-01
Chapter 2 Installing the Cisco Unified MeetingPlace 8100 Series Hardware
About Telephony Configurations for Mixed Cisco Unified MeetingPlace Systems
Figure 2-27
Back of Cisco Unified MeetingPlace 8112 (Mixed Configuration with 23 T1 PRI and 120
IP Ports)
shows the connections on the back of a Cisco Unified MeetingPlace 8112 with a mixed
Cisco Unified MeetingPlace system with 480 E1 ports and 480 IP ports.
The MP-MA-16 that is used for the IP configuration is shown on the left in slot 16.
The MP-MA-16-PRI that is used for the E1 configuration is shown on the right in slot 1. There are ten
Smart Blades (in slots 2, 3, 4, 5, 6, 11, 12, 13, 14, and 15) to support 960 ports.
