Page 47
2-23
Installation and Upgrade Guide for Cisco Unified MeetingPlace Audio Server 6.x
OL-13417-01
Chapter 2 Installing the Cisco Unified MeetingPlace 8100 Series Hardware
About Telephony Configurations for E1 and T1 PRI Cisco Unified MeetingPlace Systems
Figure 2-20
Back of Cisco Unified MeetingPlace 8112 (T1 PRI with 1 MP-MA-16-PRI)
Connecting E1 or T1 PRI Telephony Cables with One Multi Access Blade
MP-MA-4-PRI
To Connect E1 or T1 PRI Telephony Cables with One Multi Access Blade MP-MA-4-PRI
Step 1
Locate the following items that shipped with the Cisco Unified MeetingPlace Audio Server:
•
E1 or T1 PRI telephony cables.
•
Breakout box, which should already be mounted above the Cisco Unified MeetingPlace Audio
Server.
•
Trunk card interface cable assemblies (50-pin Amphenol cables).
