Ventilation Guidelines
78-13101-02
Rack Mounting Guidelines
Note To check the air baffle, the cover of the router chassis must be removed. For instructions on
removing the chassis cover, refer to Chapter 5, “Maintaining the Cisco 10720 Internet Router”,
in the Cisco 10720 Internet Router Installation and Configuration Guide.
• Check equipment located near the bottom of the rack as it can generate excessive heat that is drawn
upward and into the intake ports of equipment above, leading to possible overheat conditions.
See Figure 2 for the ventilation requirements of the Cisco 10720 Internet Router.
Figure 2 Ventilation Requirements for Cisco 10720 Internet Router
57879
6 in.
(15.24 cm)
6 in.
(15.24 cm)
0.75 in.
(1.9 cm)
0.75 in.
(1.9 cm)
