F i g u r e 1 - 1 2 . I n s t a l l i n g t h e R a c k B e z e l
thumbscrew (2)
3 Reinstall the hard drives in their slots in the drive bay, if they were removed to lighten
the ehassis (see your Installation and Troubleshooting Guide for instruetions).
5 Install the power supplies and the mieroproeessor tray, if they were removed to lighten
the ehassis.
6 Close the bezel.
7 Replaee the system eover.
Installing the System in the Rack
/i\ CAUTION: If you are installing more than one system, install the first system in
the lowest available position in the rack.
/4\ CAUTION: Never pull more than one component out of the rack at a time.
1 Pull the two interior slide assemblies out of the raek until they loek in the fully-
extended position.
R a c k I n s t a l l a t i o n G u i d e | 1-15
