System description – Welch Allyn Insight Instruments Solarc Light Source - User Manual User Manual
Page 8
4
UI-20002 6/2002
System Description
The Insight Instruments Light Source is used to supply high quality, white
light for video and optical illumination systems. It accepts Insight
Instruments ACMI connectors.
Power
Switch
Fiber
Optic
Bundle
Port
Light
Control
Knob
Fan
Grill
Fuse
Drawer
AC
Power
Input
FRONT
BACK
Mounting Post
Mounting Bracket
BOTTOM
