p.1
SYSTEM SYMBOL DESCRIPTIONS
Attention: Read Operating Manual for Warnings, Precautions,
and Instructions for Use.
Caution: Hot Surface
WARNINGS AND PRECAUTIONS
• The high intensity light at the front of the Light Source and the tip of the fiber
optic bundle will create high temperatures and bright light. To minimize the
risk of injury, avoid direct viewing or contact.
• To prevent temporary blinding and contact with heated parts, always plug the
fiber optic bundle into the Light Source before turning the power on.
• DO NOT switch the Light Source ON and OFF in rapid succession. Doing so will
dramatically shorten lamp life. After turning off, wait 10 to 15 seconds before
turning on again.
• CAUTION: PROVIDE ADEQUATE VENTILATION TO PREVENT OVERHEATING.
When using outside the carry pouch, do not drape the light source or place
the unit within 3 inches (7.62cm) of a solid object.
• USE CAUTION WHEN REPLACING LAMP. ALLOW LAMP TO COOL.
Use only Everest VIT replacement lamp #SPL-240.
• The supplied detachable power cord is the means of disconnect
from the power source.
p.10
TECHNICAL SPECIFICATIONS
Power In: 100-240VAC, 50/60, 400 HZ, 1A (@ 100VAC)
Fuse Set:
2 each T1.OA, L250V
1.OA, 250V, time lag (slow blow), low breaking capacity
Dimensions: 20.8cm (8.2 in) x 7.9cm (3.1 in) x 13.2cm (5.2 in)
Illumination System:
Lamp: HI-Lux Metal Halide, 24W, 60V, Everest VIT Part No. SPL-240
Color Temperature: 5500 o K
Lamp Life: 350 hours average
Intensity Control Manual shutter (20% to 100% full output)
Light Guide Interface: ACMI standard; switchable to Wolf, Olympus and Storz
Environment:
Operating Temperature: 0°C to 34°C (32°F to 100°F)
Operating Humidity: 0 to 95% rh
Storage Temperature: -25°C to 54°C (-13°F to 140°F)
Storage Humidity: 30 to 75% rh
Equipment Classification: Class 1, Type B, Continuous Operation
ACCESSORIES
Part No. Description
SPL-240 Replacement lamp.
ELSV-P Carry pouch with shoulder strap. Light source can be
operated inside pouch.
INV75 DC to AC inverter for use with a battery. Adapter cable
available for connection to Videoprobe XL battery belt, battery
post or vehicle cigarette lighter socket.
